Orient yourself

Unless otherwise stated, we assume you're holding the Qubi with the button facing up and the charger port facing back. So “upwards” means “in the direction of the button.”

up(button direction)back(port direction)button

Physicists have special names for the poles of the sphere. These names are shown below in the white circles. This is called the Bloch sphere mapping.

+zbutton up−z+xfront of device−xport direction+y−y01+−+i−i
How the Qubi's physical orientation maps to the Bloch sphere. Button points along +z = |0⟩, port along −x. Each pole carries its sticker.

Add stickers

The box includes a sticker sheet. Apply the six labeled stickers (−, +, 0, 1, −i, +i) to the matching poles from the figure above. These will be helpful for learning, and can be removed later.

The Qubi sticker sheet: a large gradient circle, the qolour wordmark, and a column of small stickers labeled Blanks, For later, Apply these (−, +, 0, 1, −i, +i), For later, Blanks
The sticker sheet in the box.
Placing the stickers on a Qubi.
